HypeStickyScroll

Make a Hype widget sticky in a container

Hype Sticky Scroll

Introducing Hype Sticky Scroll, a powerful and versatile tool that unlocks the potential of scroll-driven animations in your Tumult Hype projects. With this plugin, create seamless and engaging scroll-based experiences that respond dynamically to user interactions.

Key features include:

Scene filtering and ignoring: Choose which scenes to include or exclude from the sticky scroll animation (just add 🔒 to the scene name).
Customizable wrapper height: Adjust the height of the wrapper to fit your content and design.
Function callbacks: Implement custom behaviors with the stickyScrollBefore and stickyScrollAfter callbacks.
Progress tracking: Monitor the scroll progress and control playback of your animations.
Smooth scene navigation: Scroll to specific scenes or progress values with customizable durations, easing, and offsets.
Scene-time navigation: Scroll to specific timeline positions within scenes for precise animation control.
Scroll snapping: Automatically snap to predefined points with configurable tolerance zones and timing.
Lenis smooth scroll integration: Optional support for buttery-smooth scrolling with Lenis library.
Auto-scroll speed control: Configurable automatic scroll duration based on distance.

Content Delivery Network (CDN)

Latest version can be linked into your project using the following in the head section of your project:

<script src="https://cdn.jsdelivr.net/gh/worldoptimizer/HypeStickyScroll/HypeStickyScroll.min.js"></script>

Optionally you can also link a SRI version or specific releases. Read more about that on the JsDelivr (CDN) page for this extension at https://www.jsdelivr.com/package/gh/worldoptimizer/HypeStickyScroll

Learn how to use the latest extension version and how to combine extensions into one file at https://github.com/worldoptimizer/HypeCookBook/wiki/Including-external-files-and-Hype-extensions

Documentation

The Hype Sticky Scroll extension allows you to create a sticky scroll effect in your Tumult Hype projects. The extension provides an easy way to control the scroll progress and switch between scenes within a Hype document.

Getting Started

Include the Hype Sticky Scroll script in the head of your HTML document either through the resources library or using a CDN.

FAQ

Q: How do I enable the sticky scroll effect?

A: You can enable the sticky scroll effect by calling the enableStickyScroll function on the Hype document object like this:

hypeDocument.enableStickyScroll(height);

Replace height with your desired height value in pixels.

Q: How do I disable the sticky scroll effect?

A: You can disable the sticky scroll effect by calling the disableStickyScroll function on the Hype document object like this:

hypeDocument.disableStickyScroll();

Q: How do I exclude certain scenes from the sticky scroll calculation?

A: To exclude specific scenes from the sticky scroll effect, simply include the 🔒 symbol in the scene's name. This tells the Hype Sticky Scroll extension to ignore that scene when calculating the total length of the scroll effect.

Q: How can I get the current scroll progress?

A: You can get the current scroll progress by calling the getProgress function on the Hype document object like this:

hypeDocument.getProgress();

This function returns a value between 0 and 1, representing the scroll progress.

Q: How can I scroll to a specific progress value?

A: You can scroll to a specific progress value (0-1) using the scrollToProgress function:

// Instant scroll to 50% progress
hypeDocument.scrollToProgress(0.5);

// Animated scroll with options (duration in seconds)
hypeDocument.scrollToProgress(0.5, {
    duration: 1.5,        // 1.5 seconds
    easing: 'inout',      // 'linear', 'in', 'out', 'inout'
    offset: 0.1           // Additional 10% offset (also accepts '10%' or '50px')
});

// Auto-duration based on distance
hypeDocument.scrollToProgress(0.8, {
    duration: 'auto',     // Duration calculated by distance * autoScrollSpeed
    easing: 'out'
});

Q: How can I scroll to the start of a scene?

A: You can scroll to the start of a scene using the scrollToSceneStart function with an options object:

// Instant scroll
hypeDocument.scrollToSceneStart('Scene 2');

// Animated scroll with options (duration in seconds)
hypeDocument.scrollToSceneStart('Scene 2', {
    duration: 2,          // 2 seconds
    easing: 'inout',      // 'linear', 'in', 'out', 'inout'
    offset: '5%'          // Offset by 5% (also accepts 0.05 or '50px')
});

// Auto-duration based on distance
hypeDocument.scrollToSceneStart('Scene 3', {
    duration: 'auto'
});

Q: How can I scroll to a specific time within a scene?

A: You can scroll to a specific timeline position within a scene using the scrollToSceneTime function:

// Instant scroll to 3.5 seconds into Scene 2
hypeDocument.scrollToSceneTime('Scene 2', 3.5);

// Animated scroll with options
hypeDocument.scrollToSceneTime('Scene 2', 3.5, {
    duration: 1.5,
    easing: 'inout',
    offset: 0.05
});

You can also get the progress value for any scene and time:

// Get progress for Scene 2 at 3.5 seconds
const progress = hypeDocument.getProgressFromSceneTime('Scene 2', 3.5);
console.log(progress); // e.g., 0.45

Q: How do I use Lenis smooth scrolling?

A: First, load the Lenis library, then use the simple setup function:

<!-- Load Lenis library -->
<script src="https://unpkg.com/lenis@latest/dist/lenis.min.js"></script>

<!-- Load Hype Sticky Scroll -->
<script src="HypeStickyScroll.min.js"></script>

<!-- Setup Lenis (in your Hype function or custom JavaScript) -->
<script>
    // Simple setup with defaults
    HypeStickyScroll.setupLenis();

    // Or with custom options
    HypeStickyScroll.setupLenis({
        duration: 1.5,
        easing: (t) => t,
        direction: 'vertical'
    });
</script>

The extension will automatically detect Lenis and use it for smooth scrolling. All scrollToProgress and scrollToSceneStart functions will work seamlessly with Lenis.

Q: How can I configure the auto-scroll speed?

A: You can set the autoScrollSpeed default to control how fast "auto" duration scrolls:

// Default is 1 (1000px/s)
HypeStickyScroll.setDefault('autoScrollSpeed', 2); // 2000px/s (faster)
HypeStickyScroll.setDefault('autoScrollSpeed', 0.5); // 500px/s (slower)

Q: How do I setup scroll snapping?

A: Scroll snapping automatically snaps to predefined points after the user stops scrolling:

// Setup snap points for specific scenes and times
hypeDocument.setupScrollSnapping({
    snapPoints: [
        { scene: 'Intro', time: 0 },
        { scene: 'Chapter 1', time: 0 },
        { scene: 'Chapter 1', time: 2.5 },
        { scene: 'Chapter 2', time: 0 }
    ],
    tolerance: {
        before: 200,   // Snap within 200px before reaching point
        after: 50      // Snap within 50px after passing point
    },
    delay: 1000,       // Wait 1s after scroll stops
    duration: 'auto',  // Auto-calculate animation duration
    easing: 'inout'
});

You can also set default snap points globally that apply automatically:

// Set defaults BEFORE Hype document loads
HypeStickyScroll.setDefault('snapPoints', [
    { scene: 'Intro', time: 0 },
    { scene: 'Chapter 1', time: 0 },
    { scene: 'Chapter 2', time: 0 }
]);

// Snap points automatically initialize when document loads
// No need to call setupScrollSnapping()

Control snapping:

hypeDocument.disableScrollSnapping();           // Disable
hypeDocument.isScrollSnappingEnabled();         // Check status

Note: If setupScrollSnapping() is called without snap points (and no defaults are set), it will return early without enabling snapping.

Q: How do I debug snap points visually?

A: Enable debug mode to see a clean visual indicator on the right side of the screen:

// Enable debug visualization
HypeStickyScroll.setDefault('debug', true);

Debug visualization shows:

White horizontal line: Your current scroll position with scene name and time (e.g., "Persona 12.5s")
Green dots: Snap point locations (larger when you're near them)
Thin vertical lines: Tolerance zones
- Green = you're in snap range (will snap when you stop scrolling)
- Gray = inactive
- Orange = overlapping tolerance zones (conflict - see below)
Time labels: Only shown when active or overlapping
⚠️ Warning: Indicates overlapping snap points

What are overlaps? When tolerance zones of consecutive snap points overlap, both points could try to snap you simultaneously. For example:

Snap point at 12s with after: 400 extends to position X
Snap point at 16s with before: 400 starts before position X
The overlapping area (orange) means both points are "fighting" for control

How to fix overlaps: Reduce tolerance values or increase spacing between snap points.

Extended hypeDocument API

Command	Description
`hypeDocument.enableStickyScroll(height)`	Enables the sticky scroll effect with specified wrapper height.
`hypeDocument.disableStickyScroll()`	Disables the sticky scroll effect.
`hypeDocument.getProgress()`	Returns the current scroll progress (0-1).
`hypeDocument.getScrollFromProgress(progress)`	Returns the scroll position for a given progress value.
`hypeDocument.getProgressFromSceneTime(sceneName, timeInScene)`	Returns the progress value for a specific scene and timeline time.
`hypeDocument.scrollToProgress(progress, options)`	Scrolls to a specific progress value (0-1) with optional duration, easing, and offset.
`hypeDocument.scrollToSceneStart(sceneName, options)`	Scrolls to the start of a scene with optional duration, easing, and offset.
`hypeDocument.scrollToSceneTime(sceneName, timeInScene, options)`	Scrolls to a specific timeline time within a scene with optional duration, easing, and offset.
`hypeDocument.setupScrollSnapping(options)`	Enables scroll snapping with snap points and configuration.
`hypeDocument.disableScrollSnapping()`	Disables scroll snapping.
`hypeDocument.isScrollSnappingEnabled()`	Returns true if scroll snapping is enabled.

Options Object

All scroll functions (scrollToProgress, scrollToSceneStart, and scrollToSceneTime) accept an options object:

Option	Type	Default	Description
`duration`	Number or "auto"	0	Scroll duration in seconds (0 = instant, "auto" = distance-based)
`easing`	String	'inout' / 'linear'	Easing function: 'linear', 'in', 'out', 'inout'
`offset`	Number or String	0	Additional offset: fractional (0.1), percentage ('10%'), or pixels ('50px')

HypeStickyScroll API

Command	Description
`HypeStickyScroll.setDefault(key, value)`	Sets a default value for a specified key or overrides all default values at once.
`HypeStickyScroll.getDefault(key)`	Returns the value of a default by key or all default values if no key is given.
`HypeStickyScroll.setupLenis(options)`	Simple helper to setup Lenis smooth scrolling (requires Lenis library).
`HypeStickyScroll.version`	The version of the Hype Sticky Scroll extension.

Available Defaults

Default	Type	Default Value	Description
`ignoreSceneSymbol`	String	'🔒'	Symbol to exclude scenes from sticky scroll
`wrapperHeight`	Number	5000	Default wrapper height in pixels
`autoScrollSpeed`	Number	1	Speed factor in thousands of pixels per second (1 = 1000px/s)
`lenis`	Boolean	false	Enable Lenis smooth scroll integration
`lenisOptions`	Object	{...}	Default Lenis configuration options
`snapPoints`	Array	[]	Default snap points (auto-applied if set)
`snapTolerance`	Object	{before: 200, after: 50}	Default snap tolerance zones in pixels
`snapDelay`	Number	1000	Default snap delay in milliseconds
`snapDuration`	Number/String	'auto'	Default snap animation duration
`snapEasing`	String	'inout'	Default snap easing function
`debug`	Boolean	false	Enable visual debugging (snap points + scroll position)

Examples

// Change the ignore symbol
HypeStickyScroll.setDefault('ignoreSceneSymbol', '⛔');

// Set default wrapper height
HypeStickyScroll.setDefault('wrapperHeight', 8000);

// Configure auto-scroll speed
HypeStickyScroll.setDefault('autoScrollSpeed', 2); // 2000px/s

// Customize Lenis options
HypeStickyScroll.setDefault('lenisOptions', {
    duration: 2,
    easing: (t) => Math.min(1, 1.001 - Math.pow(2, -10 * t)),
    direction: 'vertical',
    smooth: true
});

// Enable debug visualization
HypeStickyScroll.setDefault('debug', true);
