Hype Sound Controller

This is a sound management API for Tumult Hype documents, allowing for instance management, bucketing, persistent muting, and more. This extension simplifies audio handling within your Hype projects, providing a robust layer of control beyond the standard audio actions.

Setup in Tumult Hype

1. Download the JavaScript file: Obtain the HypeSoundController.js file.
2. Add to Hype Resources: In your Hype document, go to the 'Resources' panel. Click the '+' button at the bottom and select 'Add File...' or simply drag and drop the HypeSoundController.js file into the Resources library.
3. Ensure it's included in the head: Make sure the checkbox for "Include in document " is checked for the added JavaScript file.

That's it! The Hype Sound Controller API will automatically be available within your Hype document's JavaScript functions and on the hypeDocument object.

Basic Usage

To use the sound controller, you'll first need to load a sound. A good place to do this is in a new JavaScript function that runs On Scene Load for your first scene.

1. Create a new JavaScript function in Hype:

• In the 'Resources' panel, click the '+' and select 'Add JavaScript Function'.
• Give it a descriptive name (e.g., setupSounds).

2. Add the following code to the function:

function setupSounds(hypeDocument, element, event) {
    // Load a sound file from the Resources library
    hypeDocument.loadSound('my-background-music.mp3', {
        alias: 'backgroundMusic',
        loop: true
    });

    // Load another sound
    hypeDocument.loadSound('click-sound.wav', {
        alias: 'click'
    });
}

3. Trigger this function:

• Select your first scene.
• In the 'Scene Inspector', click 'On Scene Load' and choose 'Run JavaScript...' and select your setupSounds function.

4. Play the sound:

You can now play this sound from anywhere in your Hype document, for example, on a button click.

• Select a button element.
• In the 'Actions Inspector', choose 'On Mouse Click' -> 'Run JavaScript...' -> 'New Function'.
• In the new function, add:

function playMusicOnClick(hypeDocument, element, event) {
    hypeDocument.playSound('backgroundMusic');
}

---

API Reference

Once the script is installed, all functions are available on the hypeDocument object.

hypeDocument.loadSound(filename, options)

Prepares a sound for playback.

• filename (String): The name of the sound file in the Hype Resources library (e.g., 'my-sound.mp3') or a full path to an external sound file.
• options (Object): An optional object to configure the sound's behavior.
  • alias (String): A unique name to refer to this sound. If not provided, it defaults to the filename without the extension.
  • bucket (String): The name of the sound group this belongs to. Defaults to 'default'.
  • loop (Boolean): Whether the sound should loop. Defaults to false.
  • volume (Number): The volume from 0.0 to 1.0. Defaults to 1.0.
  • stopOthers (Boolean): Whether to stop other sounds when this one plays. Defaults to true.
  • fadeIn (Number): Fade-in duration in seconds. Defaults to 0.
  • fadeOut (Number): Fade-out duration in seconds. Defaults to 0.

hypeDocument.playSound(alias, options)

Plays a loaded sound.

• alias (String): The alias of the sound to play.
• options (Object): An optional object to override the default or load-time options for this specific playback instance.

hypeDocument.pauseSound(alias, options)

Pauses a playing sound, with an optional fade-out.

• alias (String): The alias of the sound to pause.
• options (Object):
  • fadeOut (Number): Duration in seconds to fade out before pausing.

hypeDocument.resumeSound(alias, options)

Resumes a paused sound, with an optional fade-in.

• alias (String): The alias of the sound to resume.
• options (Object):
  • fadeIn (Number): Duration in seconds to fade in when resuming.

hypeDocument.stopSound(alias, options)

Stops a sound and resets its playback to the beginning.

• alias (String): The alias of the sound to stop.
• options (Object):
  • fadeOut (Number): Duration in seconds to fade out before stopping.

hypeDocument.stopAllSounds(bucket)

Stops all sounds, or all sounds within a specific bucket.

• bucket (String, optional): The name of the bucket to stop sounds in. If omitted, all sounds from all buckets will be stopped.

---

Examples and Use Cases

Fading Sounds (fadeIn/fadeOut)

You can create smooth audio transitions by using the fadeIn and fadeOut options. The duration is specified in seconds.

Example: Have background music fade in when a scene loads and fade out when a button is clicked.

1. Load the sound in your setup function:

   function setupSounds(hypeDocument, element, event) {
       // We can set a default fadeOut time for this sound when we load it.
       hypeDocument.loadSound('ambient-music.mp3', {
           alias: 'ambient',
           loop: true,
           fadeOut: 2.5 // Default fade-out of 2.5 seconds
       });
   }


2. On Scene Load, play the sound with a fade-in:

   function startMusic(hypeDocument, element, event) {
       // This will override any default fadeIn and start playing the music,
       // fading it in from volume 0 to 1 over 4 seconds.
       hypeDocument.playSound('ambient', { fadeIn: 4 });
   }


3. On a button click, stop the sound with a fade-out:

   function stopMusic(hypeDocument, element, event) {
       // Since we set a default fadeOut of 2.5 seconds when loading,
       // we don't need to specify it again here.
       // The music will fade to silence over 2.5 seconds before stopping.
       hypeDocument.stopSound('ambient');
   }


Sound Buckets

Buckets are a powerful feature for managing groups of sounds. For example, you can have a 'background' bucket and an 'sfx' bucket.

Example:

// On Scene Load (in your setup function)
hypeDocument.loadSound('ambient-music.mp3', { alias: 'ambient', bucket: 'background', loop: true });
hypeDocument.loadSound('button-hover.wav', { alias: 'hover', bucket: 'sfx', stopOthers: false });
hypeDocument.loadSound('button-click.wav', { alias: 'click', bucket: 'sfx', stopOthers: false });

// Later, to stop only the sound effects:
hypeDocument.stopAllSounds('sfx');

Muting

You can mute and unmute sounds globally or on a per-bucket basis. This state is persistent.

• hypeDocument.muteAllSounds(bucket): Mutes all sounds or just a specific bucket.
• hypeDocument.unmuteAllSounds(bucket): Unmutes all sounds or just a specific bucket.
• hypeDocument.isMuted(bucket): Returns true if all sounds or a specific bucket is muted.

Example: Creating a mute toggle button.

function toggleMute(hypeDocument, element, event) {
    if (hypeDocument.isMuted()) {
        hypeDocument.unmuteAllSounds();
        element.innerHTML = 'Mute';
    } else {
        hypeDocument.muteAllSounds();
        element.innerHTML = 'Unmute';
    }
}

Custom Behavior Triggers

The sound controller can trigger Custom Behaviors in Hype, allowing you to chain animations and other actions to audio events without writing extra code.

• Audio Started: Triggered when any sound starts playing.
• Audio Started [alias]: Triggered when a specific sound starts (e.g., Audio Started ambient).
• Audio Ended: Triggered when any sound finishes.
• Audio Ended [alias]: Triggered when a specific sound finishes.
• Audio Failed: Triggered if a sound fails to play (e.g., due to browser restrictions).
• Audio Failed [alias]: Triggered when a specific sound fails.

To use these, create a new Custom Behavior in the Scene or Symbol inspector and give it one of the names above. You can then add Hype actions (like starting a timeline) to this behavior.

---

Advanced API

HypeSoundController.setDefault(key, value) or HypeSoundController.setDefault({key: value})

You can change the global default settings for all sounds. This is useful for setting project-wide defaults. You would typically run this in a function on the first scene load. This function is called on the global HypeSoundController object, not hypeDocument.

Example: All sounds should loop by default.

function setGlobalSoundDefaults(hypeDocument, element, event) {
    HypeSoundController.setDefault('loop', true);
}

HypeSoundController.getDefault(key)

Retrieves a specific default setting or the entire default object.

playOnlyInBucket(bucketName, aliasToPlay, options)

A useful helper function that stops all other sounds in a specified bucket and plays only the desired sound. This is great for managing mutually exclusive sounds, like tracks on a playlist.

Example: A playlist where only one song can play at a time.

// Load sounds into a 'playlist' bucket
hypeDocument.loadSound('song1.mp3', { alias: 'song1', bucket: 'playlist' });
hypeDocument.loadSound('song2.mp3', { alias: 'song2', bucket: 'playlist' });

// Function for a button to play song 1
function playSong1(hypeDocument, element, event) {
    hypeDocument.playOnlyInBucket('playlist', 'song1', { fadeIn: 1 });
}

// Function for a button to play song 2
function playSong2(hypeDocument, element, event) {
    hypeDocument.playOnlyInBucket('playlist', 'song2', { fadeIn: 1 });
}
